The Chern class of the sheaf of logarithmic derivations along a simple normal crossing divisor equals the Chern-Schwartz-MacPherson class of the complement of the divisor. We extend this equality to more general divisors, which are locally analytically isomorphic to free hyperplane arrangements.
We study the behavior of the Chern classes of graph hypersurfaces under the operation of deletion-contraction of an edge of the corresponding graph. We obtain an explicit formula when the edge satisfies two technical conditions, and prove that both these conditions hold when the edge is multiple in the graph. This leads to recursions for the Chern classes of graph hypersurfaces for graphs obtained by adding parallel edges to a given (regular) edge. Analogous results for the case of Grothendieck classes of graph hypersurfaces were obtained in previous work. Both Grothendieck classes and Chern classes were used to define `algebro-geometric' Feynman rules. The results in this paper provide further evidence that the polynomial Feynman rule defined in terms of the Chern-Schwartz-MacPherson class of a graph hypersurface reflects closely the combinatorics of the corresponding graph. The key to the proof of the main result is a more general formula for the Chern-Schwartz-MacPherson class of a transversal intersection (see section 3), which may be of independent interest. We also describe a more geometric approach, using the apparatus of `Verdier specialization'.
We describe an approach to the study of phase transitions in Potts models based on an estimate of the complexity of the locus of real zeros of the partition function, computed in terms of the classes in the Grothendieck ring of the affine algebraic varieties defined by the vanishing of the multivariate Tutte polynomial. We give completely explicit calculations for the examples of the chains of linked polygons and of the graphs obtained by replacing the polygons with their dual graphs. These are based on a deletion-contraction formula for the Grothendieck classes and on generating functions for splitting and doubling edges.
We show that the characteristic polynomial of a hyperplane
arrangement can be recovered from the class in the Grothendieck group
of varieties of the complement of the arrangement. This gives a quick
proof of a theorem of Orlik and Solomon relating the characteristic
polynomial with the ranks of the cohomology of the complement of the
arrangement.
We also show that the characteristic polynomial can be computed
from the total Chern class of the complement of the arrangement; this
has also been observed by Huh. In the case of free arrangements, we
prove that this Chern class agrees with the Chern class of the dual of
a bundle of differential forms with logarithmic poles along the
hyperplanes in the arrangement; this follows from work of Mustata
and Schenck. We conjecture that this relation holds for all free
divisors.
We give an explicit relation between the characteristic polynomial
of an arrangement and the Segre class of its singularity (`Jacobian')
subscheme. This gives a variant of a recent result of Wakefield and
Yoshinaga, and shows that the Segre class of the singularity subscheme
of an arrangement together with the degree of the arrangement
determine the ranks of the cohomology of its complement.
We also discuss the positivity of the Chern classes of hyperplane
arrangements: we give a combinatorial interpretation of this
phenomenon, and we discuss the cases of generic and free arrangements.
Let X in V be a closed embedding, with V - X nonsingular. We define
a constructible function on X, agreeing with Verdier's specialization
of the constant function 1 when X is the zero-locus of a function on
V. Our definition is given in terms of an embedded resolution of X;
the independence on the choice of resolution is obtained as a
consequence of the weak factorization theorem of Abramovich et al.
The main property of the specialization function is a compatibility
with the specialization of the Chern class of the complement V-X. With
the definition adopted here, this is an easy consequence of standard
intersection theory. It recovers Verdier's result when X is the
zero-locus of a function on V.
Our definition has a straightforward counterpart in a motivic
group. The specialization function and the corresponding Chern class
and motivic aspect all have natural `monodromy' decompositions, for
for any X in V as above.
The definition also yields an expression for Kai Behrend's
constructible function when applied to (the singularity subscheme of)
the zero-locus of a function on V.
We prove a deletion-contraction formula for motivic Feynman rules given by the classes of the affine graph hypersurface complement in the Grothendieck ring of varieties. We derive explicit recursions and generating series for these motivic Feynman rules under the operation of multiplying edges in a graph and we compare it with similar formulae for the Tutte polynomial of graphs, both being specializations of the same universal recursive relation. We obtain similar recursions for graphs that are chains of polygons and for graphs obtained by replacing an edge by a chain of triangles. We show that the deletion-contraction relation can be lifted to the level of the category of mixed motives in the form of a distinguished triangle, similarly to what happens in categorifications of graph invariants.
We give a general procedure to construct algebro-geometric Feynman rules, that is, characters of the Connes--Kreimer Hopf algebra of Feynman graphs that factor through a Grothendieck ring of immersed conical varieties, via the class of the complement of the affine graph hypersurface. In particular, this maps to the usual Grothendieck ring of varieties, defining motivic Feynman rules. We also construct an algebro-geometric Feynman rule with values in a polynomial ring, which does not factor through the usual Grothendieck ring, and which is defined in terms of characteristic classes of singular varieties. This invariant recovers, as a special value, the Euler characteristic of the projective graph hypersurface complement. The main result underlying the construction of this invariant is a formula for the characteristic classes of the join of two projective varieties. We discuss the BPHZ renormalization procedure in this algebro-geometric context and some motivic zeta functions arising from the partition functions associated to motivic Feynman rules.
The subring of the Grothendieck ring of varieties generated by the
graph hypersurfaces of quantum field theory maps to the monoid ring of
stable birational equivalence classes of varieties. We show that the
image of this map is the copy of Z generated by the class of a
point.
Thus, the span of the graph hypersurfaces in the Grothendieck ring
is nearly killed by setting the Lefschetz motive L to zero,
while it is known that graph hypersurfaces generate the Grothendieck
ring over a localization of Z[L] in which L
becomes invertible. In particular, this shows that the graph
hypersurfaces do
not generate the Grothendieck ring prior to localization.
The same result yields some information on the mixed Hodge
structures of graph hypersurfaces, in the form of a constraint on the
terms in their Deligne-Hodge polynomials.
The purpose of this paper is to show that, under certain combinatorial conditions on the graph, parametric Feynman integrals can be realized as periods on the complement of the determinant hypersurface in an affine space depending on the number of loops of the Feynman graph. The question of whether the Feynman integrals are periods of mixed Tate motives can then be reformulated (modulo divergences) as a question on a relative cohomology being a realization of a mixed Tate motive. This is the cohomology of the pair of the determinant hypersurface complement and a normal crossings divisor depending only on the number of loops and the genus of the graph. We show explicitly that this relative cohomology is a realization of a mixed Tate motive in the case of three loops and we give alternative formulations of the main question in the general case, by describing the locus of intersection of the divisor with the determinant hypersurface complement in terms of intersections of unions of Schubert cells in flag varieties. We also discuss different methods of regularization aimed at removing the divergences of the Feynman integral.
We present new explicit constructions of weak coupling limits of F-theory generalizing Sen's construction to elliptic fibrations which are not necessary given in a Weierstrass form. These new constructions allow for an elegant derivation of several brane configurations that do not occur within the original framework of Sen's limit, or which would require complicated geometric tuning or break supersymmetry. Our approach is streamlined by first deriving a simple geometric interpretation of Sen's weak coupling limit. This leads to a natural way of organizing all such limits in terms of transitions from semistable to unstable singular fibers. These constructions provide a new playground for model builders as they enlarge the number of supersymmetric configurations that can be constructed in F-theory. We present several explicit examples for E8, E7 and E6 elliptic fibrations.
We extend the classical formula of Porteous for blowing-up Chern classes
to the case of blow-ups of possibly singular varieties along regularly
embedded centers.
The proof of this generalization is perhaps conceptually simpler than the
standard argument for the nonsingular case, involving Riemann-Roch
without denominators. The new approach
relies on the explicit computation of an ideal, and a mild generalization
of a well-known formula for the normal bundle of a proper transform.
We also discuss alternative, very short proofs of the standard
formula in some cases: an approach relying on the theory of
Chern-Schwartz-MacPherson classes (working in characteristic 0), and
an argument reducing the formula to a straightforward computation of
Chern classes for sheaves of differential 1-forms with logarithmic
poles (when the center of the blow-up is a complete intersection).
Every complex plane curve C determines a subscheme S
of the P8 of 3x3 matrices, whose projective
normal cone (PNC) captures subtle invariants of C.
In a previous paper (FSU07-15) we obtain a set-theoretic
description of the PNC and thereby we determine all possible limits of
families of plane curves whose general element is isomorphic to
C. The main result of this article is the determination of the
PNC as a cycle; this is an essential ingredient in our
computation in Linear orbits of arbitrary plane curves,
Michigan Math J., 48 (2000) 1-37, of the degree of the
PGL(3)-orbit closure of an arbitrary plane curve, an invariant of
natural enumerative significance.
We classify all possible limits of families of translates of a fixed, arbitrary complex plane curve. We do this by giving a set-theoretic description of the projective normal cone (PNC) of a subscheme, determined by the curve, of the P8 of 3x3 matrices. In a sequel to this paper we determine the multiplicities of the components of the PNC. The knowledge of the PNC as a cycle is essential in our computation of the degree of the PGL(3)-orbit closure of an arbitrary plane curve, performed in Linear orbits of arbitrary plane curves, Michigan Math J., 48 (2000) 1-37.
We consider the infinite family of Feynman graphs known as the ``banana graphs'' and compute explicitly the classes of the corresponding graph hypersurfaces in the Grothendieck ring of varieties as well as their Chern--Schwartz--MacPherson classes, using the classical Cremona transformation and the dual graph, and a blowup formula for characteristic classes. We outline the interesting similarities between these operations and we give formulae for cones obtained by simple operations on graphs. We formulate a positivity conjecture for characteristic classes of graph hypersurfaces and discuss briefly the effect of passing to noncommutative spacetime.
In light of Sen's weak coupling limit of F-theory as a type IIB orientifold, the compatibility of the tadpole conditions leads to a non-trivial identity relating the Euler characteristics of an elliptically fibered Calabi-Yau fourfold and of certain related surfaces. We present the physical argument leading to the identity, and a mathematical derivation of a Chern class identity which confirms it, after taking into account singularities of the relevant loci. This identity of Chern classes holds in arbitrary dimension, and for varieties that are not necessarily Calabi-Yau. Singularities are essential in both the physics and the mathematics arguments: the tadpole relation may be interpreted as an identity involving stringy invariants of a singular hypersurface, and corrections for the presence of pinch-points. The mathematical discussion is streamlined by the use of Chern-Schwartz-MacPherson classes of singular varieties. We also show how the main identity may be obtained by applying `Verdier specialization' to suitable constructible functions.
We give explicit formulas for the Chern-Schwartz-MacPherson classes of all Schubert varieties in the Grassmannian of $d$-planes in a vector space, and conjecture that these classes are effective. We prove this is the case for (very) small values of $d$.
We give a short proof of the fact that the Chern classes for singular varieties defined by Marie-Hélène Schwartz by means of "radial frames" agree with the functorial notion defined by Robert MacPherson.
We introduce a formal integral on the system of varieties mapping
properly and birationally to a given one, with value in an associated
Chow group. Applications include comparisons of Chern numbers of
birational varieties, new birational invariants, `stringy' Chern
classes, and a `celestial' zeta function specializing to the
topological zeta function.
In its simplest manifestation, the integral gives a new expression for
Chern-Schwartz-MacPherson classes of possibly singular varieties,
placing them into a context in which a `change of variable' formula
holds.
The formalism has points of contact with motivic integration.
We define an `enriched' notion of Chow groups for algebraic varieties, agreeing with the conventional notion for complete varieties, but enjoying a functorial push-forward for arbitrary maps. This tool allows us to glue intersection-theoretic information across elements of a stratification of a variety; we illustrate this operation by giving a direct construction of Chern-Schwartz-MacPherson classes of singular varieties, providing a new proof of an old (and long since settled) conjecture of Deligne and Grothendieck.
We introduce the notion of {\em proChow group\/} of varieties, agreeing with the notion of Chow group for complete varieties and covariantly functorial with respect to {\em arbitrary\/} morphisms. We construct a natural transformation from the functor of constructible functions to the proChow functor, extending MacPherson's natural transformation. We illustrate the result by providing very short proofs of (a generalization of) two well-known facts on Chern-Schwartz-MacPherson classes.
We introduce a notion of integration on the category of proper
birational maps to a given variety $X$, with value in an associated
Chow group. Applications include new birational invariants; comparison
results for Chern classes and numbers of nonsingular birational
varieties; `stringy' Chern classes of singular varieties; and
a zeta function specializing to the topological zeta function.
In its simplest manifestation, the integral gives a new expression for
Chern-Schwartz-MacPherson classes of possibly singular varieties,
placing them into a context in which a `change-of-variable' formula
holds.
We study different notions of blow-up of a scheme X along a
subscheme Y, depending on the datum of an embedding of X into an
ambient scheme. The two extremes in this theory are the ordinary
blow-up, BlYX, corresponding to the identity X -> X,
and the `quasi-symmetric blow-up', BlYX, corresponding to an
embedding X -> M into a nonsingular variety M. We prove that this latter
blow-up is intrinsic of Y and X, and is universal with respect to the
requirement of being embedded as a subscheme of the ordinary blow-up of
some ambient space along Y.
We consider these notions in the context of the theory of characteristic
classes of singular varieties. We prove that if X a hypersurface in a
nonsingular variety and Y is its `singularity subscheme', these two
extremes embody respectively the conormal and characteristic
cycles of X. Consequently, the first carries the essential information
computing Chern-Mather classes, and the second is likewise a carrier for
Chern-Schwartz-MacPherson classes. In our approach, these classes are
obtained from Segre class-like invariants, in precisely the same way as
other intrinsic characteristic classes such as those proposed by William
Fulton, and by W. Fulton and Kent Johnson.
We also identify a condition on the singularities of a hypersurface
under which the quasi-symmetric blow-up is simply the linear fiber space
associated with a coherent sheaf.
Let $\varphi: V\dashrightarrow W$ be a birational map between
smooth algebraic varieties which does not change the canonical class
(in the sense of Batyrev). We prove that the total homology Chern
classes of $V$ and $W$ are push-forwards of the same class from a
resolution of indeterminacies of $\varphi$.
For example, it follows that the push-forward of the total Chern class
of a crepant resolution of a singular variety is independent of the
resolution.
We discuss an algorithm computing the push-forward to projective space of several classes associated to a (possibly singular, reducible, nonreduced) projective scheme. For example, the algorithm yields the topological Euler characteristic of the support of a projective scheme $S$, given the homogeneous ideal of $S$. The algorithm has been implemented in Macaulay2, and it is available here.
Considerations based on the known relation between different characteristic classes for singular hypersufaces suggest that a form of the `inclusion-exclusion' principle may hold for Segre classes. We formulate and prove such a principle for a notion closely related to Segre classes. This is used to provide a simple computation of the classes introduced in our previous work, in certain special (but representative) cases.
We propose a variation of the notion of Segre class, by forcing a naive `inclusion-exclusion' principle to hold. The resulting class is computationally tractable, and is closely related to Chern-Schwartz-MacPherson classes. We deduce several general properties of the new class from this relation, and obtain an expression for the Milnor class of an arbitrary scheme in terms of this class.
We show that the Chern-Schwartz-MacPherson class of a hypersurface X in a nonsingular variety M `interpolates' between two other notions of characteristic classes for singular varieties, provided that the singular locus of X is smooth and that certain numerical invariants of X are constant along this locus. This allows us to define a lift of the Chern-Schwartz-MacPherson class of such `nice' hypersurfaces to intersection homology. As another application, the interpolation result leads to an explicit formula for the Chern-Schwartz-MacPherson class of X in terms of its polar classes.
We introduce a class extending the notion of Chern-Mather class to possibly nonreduced schemes, and use it to express the difference between Schwartz- MacPherson's Chern class and the class of the virtual tangent bundle of a singular hypersurface of a nonsingular variety. Applications include constraints on the possible singularities of a hypersurface and on contacts of nonsingular hypersurfaces, and multiplicity computations.
The `linear orbit' of a plane curve of degree d is its orbit in \P^{d(d+3)/2} under the natural action of \PGL(3). In this paper we obtain an algorithm computing the degree of the closure of the linear orbit of an arbitrary plane curve, and give explicit formulas for plane curves with irreducible singularities. The main tool is an intersection-theoretic study of the projective normal cone of a scheme determined by the curve in the projective space \P^8 of 3x3 matrices; this expresses the degree of the orbit closure in terms of the degrees of suitable loci related to the limits of the curve. These limits, and the degrees of the corresponding loci, have been established in previous work.
The `linear orbit' of a plane curve of degree d is its orbit in P^{d(d+3)/2} under the natural action of PGL(3). We classify curves with positive dimensional stabilizer, and we compute the degree of the closure of the linear orbits of curves supported on unions of lines. Together with the results of [3], this encompasses the enumerative geometry of all plane curves with small linear orbit. This information will serve elsewhere as an ingredient in the computation of the degree of the orbit closure of an arbitrary plane curve.
The `linear orbit' of a plane curve of degree d is its
orbit in P^{d(d+3)/2} under the natural action of PGL(3). In
this paper we compute the degree of the closure of the linear orbits
of most curves with positive dimensional stabilizers. Our tool is a
nonsingular variety dominating the orbit closure, which we construct
by a blow-up sequence mirroring the sequence yielding an embedded
resolution of the curve.
The results given here will serve as an ingredient in the computation
of the analogous information for arbitrary plane curves. Linear
orbits of smooth plane curves are studied in [A-F1].
We express the Chern-Schwartz-MacPherson class of a possibly singular variety in terms of the total Chern class of a bundle of forms with logarithmic poles. As an application, we obtain a formula for the Chern-Schwartz-MacPherson class of a hypersurface of a nonsingular variety, in terms of the Chern-Mather class of a suitable sheaf.
We prove a formula relating Chern-Schwartz-MacPherson's class of a hypersurface in a nonsingular variety to other definitions of homology Chern classes of singular varieties, such as Mather's Chern class and a class introduced by W. Fulton.
We compute the Euler obstruction and Mather's Chern class of the discriminant hypersurface of a very ample linear system on a nonsingular variety. Comparing the codimension-1 and 2 terms of this and other characteristic classes of the discriminant leads to a quick computation of the degrees of the loci of cuspidal and binodal sections of a very ample line bundle on a smooth variety, and of the tacnodal locus for linear systems on a surface. We also compute explicitly all terms in the Schwartz-MacPherson's classes of strata of the discriminant of cubic plane curves, and of the discriminants of O(d) on P^1.
This ridiculously short note is devoted to the proof of the following
fact: if \alpha is a class of rank r in the Grothendieck group of
vector bundles over a scheme, and L is a line bundle, then
c_{r+1}(\alpha) = c_{r+1}(\alpha\otimes [L]).
The proof is elementary. Maybe the most interesting thing about this
is that it shows up with surprising frequence in intersection-theoretic
computations inspired by enumerative geometry.
Let Y be the singular locus of a hypersurface X in a smooth variety M,
with the scheme structure defined by the Jacobian ideal of X (we will
say then that Y is the singular {\it scheme\/} of X, to emphasize that
the scheme structure of Y is important for our considerations). In
this note we consider a class in the Chow group of~Y which arises
naturally in this setup, and which captures much
intersection-theoretic information about the situation. We produce
constraints for a given scheme to be a singular scheme of a
hypersurface, and we obtain applications to duality recovering, and
sometime strengthening, results of Holme, Landman, Ein, and Zak.
The degree of the dimension-0 component of our class agrees with a
known generalization, due to Parusinski, of the usual Milnor number.
Given a graph G (or more generally a matroid embedded in a projective space), we construct a sequence of algebraic varieties whose geometry encodes combinatorial information about G. For example, the chromatic polynomial of G can be computed as an intersection product of certain classes on these varieties, or recovered in terms of the Segre classes of related subschemes of a projective space; other information such as Crapo's invariant also finds a very natural geometric counterpart. The note presents this construction, and gives `geometric' proofs of a number of standard combinatorial results on the chromatic polynomial and Crapo's invariant.
We prove that MacPherson's total Chern class of a singular
hypersurface agrees `numerically' with a class obtained by means of
Fulton's intrinsic class of a scheme. More precisely, for a
hypersurface X with Jacobian scheme J, and any positive integer t,
consider the class P(X,J,t) obtained by taking Fulton's class of the
t-thickening of X along J. Then P(X,J,t) is a polynomial in t (with
coefficients in the Chow group of X), and we show that P(X,J,-1)
agrees with MacPherson's class of X after push-forward via the map
defined by the linear system of X.
We conjecture the equality holds at the level of Chow groups, and
speculate that a similar result should hold for arbitrary algebraic
schemes in characteristic 0.
Orbit closures of sets of points of the projective line under the action of the automorphism group of the latter are studied in terms of their degree and multiplicity along their boundary.
We compute the multiplicity of the discriminant of a line bundle L over a nonsingular variety S at a given section X, in terms of the Chern classes of L and of the cotangent bundle of S, and the Segre classes of the jacobian scheme of X in S. For S a surface, we obtain a precise formula that expresses the multiplicity as a sum of a term due to the non-reduced components of the section, and a aterm that depends on the Milnor numbers of the singularities of Xred. Also, under certain hypotheses, we provide fromulae for the `higher discriminants' that parametrize sections with a singular point of prescribed multiplicity. As an application, we obtain criteria for the various discriminants to be `small'.
A desingularization of the orbit closures of plane curves under the action of the automorphism group of the plane is constructed and used to study such orbits, obtaining the degree of the orbit closure of an arbitrary smooth curve in terms of its degree and of the nature of its flexes and its automorphism group. The result has a transparent enumerative interpretation.
We use a sequence of blow-ups over the projective space parametrizing plane curves of a degree d to obtain some enumerative results concerning smooth plane curves of arbitrary degree. For d=4, this gives a first modern verification of results of H. G. Zeuthen.
We employ a variety of complete cubics to give formulas for the characteristic numbers of families parametrized by hypersurfaces F in the P9 of plane cubics, in terms of infromation easily accessible given the equation of F. As examples, we obtain explicit results for families of cubics with given j-invariant and for other families arising naturally from the geometry of plane cubics.
Two blow-ups over the projective space P^N parametrizing plane curves of a given degree yield a compactification of the space of reduced curve used elsewhere to obtain partial enumerative results for families of nonsingular plane curves. In this paper it is shown how to employ the construction to obtain enumerative results for families of plane curves with a node or a cusp. The results recover known results for cubics, give a first modern verification of some computation of Zeuthen's for quartics, and are new for higher degree. The heart of the computation is the derivation of key Segre classes relating the intersection calculus at the different stages of the blow-up construction.
The variety of complete cubics obtained elsewhere is used to recover classical enumerative results for singular plane cubics, and obtain new results for cubic curves with prescribed conditions with respects to flags in the plane.
We construct a variety of complete plane cubics by a sequence of five blow-ups over P9. This enables us to translate the problem of computing characteristic numbers for a family of plane cubics into one of computing five Segre classes, and to recover classic enumerative results of Zeuthen and Maillard.
The characteristic numbers for the family of smooth plane cubics are computed, verifying results of Maillard and Zeuthen.
We survey some notions of characteristic classes for singular varieties, with particular attention devoted to the recently introduced notion of `stringy' Chern classes.
Quantum Cohomology at the Mittag-Leffler Institute
Fare Matematica. Astratto e concreto nella matematica elementare.
Algebra: Chapter 0.
